The briquetting machine is primarily used for pressing powdery materials that are difficult to form. Its key features include high forming pressure, adjustable main machine speed, and a spiral feeding mechanism.
Widely applied across industries such as metallurgy, chemicals, energy, and environmental recycling, it is primarily utilized to process difficult-to-form dry powder materials—including iron powder, pulverized coal, slag, steel dust, and aluminum ash—thereby facilitating resource reuse.
The material undergoes preliminary compaction by a pre-compression screw to achieve a specific density; it is then force-fed through an inlet and directed between two press rollers. The surfaces of these rollers feature corresponding hemispherical cavities arranged in a checkerboard pattern. With the rollers positioned horizontally, the material is drawn into the gap between them and compressed into a continuous strip of formed balls. The extrusion process ceases at the plane of the rollers' central axes; as the rollers continue to rotate, the pressure decreases. Consequently, the formed balls undergo slight elastic expansion, causing them to detach from the walls of the cavities and facilitating their smooth release from the mold.
Utilizing powerful double-roller extrusion technology, this system achieves single-pass molding—even for materials that are typically difficult to form—producing briquettes characterized by high strength and high density.
Featuring low power consumption and a minimal overall footprint, the equipment is easy to install and relocate.
Incorporating a negative-pressure or fully enclosed design, the system minimizes dust leakage during production, thereby meeting environmental protection standards and reducing material loss during transportation.
An advanced hydraulic system automatically regulates pressure, while the use of wear-resistant materials for key components facilitates routine inspection, maintenance, and adjustment.
